We manufacture hydraulic pusher centrifuge for continuous solid-liquid separation where process control is important. The hydraulic system controls cake pushing movement, so stroke and speed can be adjusted as per material behavior. This helps in handling uneven or changing feed conditions without affecting output. Slurry enters the rotating basket. Liquid passes through the screen, and solids form a layer inside. The hydraulic pusher then moves the cake step by step towards discharge. Process runs continuously with stable performance. It supports multi-stage washing for better product purity. We provide machine in SS-304, SS-316, SS-316L and duplex grades, with screen sizes as per micron requirement. This setup suits applications where consistent discharge and controlled handling are needed.
A Centrifuge Machine Is Normally Used For Seperation Of Solid / Liquid Mass. A Pusher Centrifuge Has Several Advantages Over Normal Mechanical Centrifuge Machine, Which Can Be Stated As Follows.
Wide Range Of Pusher Centrifuges Offered By Falgun Engineering Enterprise.
Presently We Are Manufacturing Four Different Models To Suit Customer's Requirements. The Machines Are Offered In SS-2205, SS-316L, SS-316, SS-304 as Contact Parts and MS Material of Other Construction, With Various Washing Modes As Optional. The Range Presently Offered Is As Follows With Approximate Capacity Of These Machines Mentioned.
| TECHNICAL DATA FOR ALL OUR MODEL OF HYDRAULIC PUSHER CENTRIFUGE | |||||
|
SR. NO. |
MODEL NAME |
MOTOR H.P. |
MEE SALT OUTPUT |
NACL SALT OUTPUT |
PUMP |
|---|---|---|---|---|---|
|
1) |
FEE – HP250 |
12.5 HP (7.5HP + 5HP) |
200-500 KG/HOUR |
1000-1500 KG/HR |
TRIPLE SCREW PUMP |
|
2) |
FEE - HP320 |
17.5 HP (10HP +7.5HP) |
500-750 KG/HOUR |
2000-3000 KG/HR |
TRIPLE SCREW PUMP |
|
3) |
FEE - HP360 |
17.5 HP (10HP +7.5HP) |
700-1000 KG/HOUR |
3000-4500 KG/HR |
TRIPLE SCREW PUMP |
|
4) |
FEE - HP400 |
25 HP (15HP + 10 HP) |
1000-1800 KG/HOUR |
5000-7000 KG/HOUR |
TRIPLE SCREW PUMP |
|
5) |
FEE - HP500 |
30 HP (20HP + 10 HP) |
2000-3000 KG/HOUR |
8000-10000 KG/HR |
TRIPLE SCREW PUMP |
|
6) |
FEE - HP600 |
50 HP (30HP + 20 HP) |
3000-4000 KG/HOUR |
10000-14000 KG/HR |
TRIPLE SCREW PUMP |
|
7) |
FEE – HP700 |
65 HP (40HP + 25 HP) |
4000-5500 KG/HOUR |
14000-18000 KG/HR |
TRIPLE SCREW PUMP |
|
MOC AVAILABLE:- SS 316, SS 316L, DUPLEX STEEL 2205, SUPER DUPLEX 2507 |
|||||
